Introduction
Applicable to compression strength test of cement,mortar,tiles and bricks,rocks and other materials;
Features:
1) precise gapless ball screw, high stiffness, good stability, double-column loading frame.
2) with high precise load sensor, good stability to ensure the accuracy of load.
3) with touch pad control system, 10.2" screen, TFT true color, high resolution (1024*1024)
4) automatic return after test, intelligent, efficient and quick.
5) the rotatable support can be adjusted freely.
6) multi-function protection: overvoltage protection, overcurrent protection, overload protection, safe protection when specimen breaks.
2. Technical Specification
1) Max. test force£¨kN): 300
2) measuring range of load: 1%-100% of full scale
3) relative error of indicating value: less than ¡À1%
4) load resolution: 0.01kN
5) loading speed: 0.05-8.0kN/s
6) moving speed of screws: 0.05-40mm/min
7) stroke of screw: 0-100mm
8) Max. test space: 200mm
9) diameter of pressure platen: Ø150mm
10) distance between columns: 300mm
11) working voltage: 220V, 50Hz
12) power: 1000W
13) dimension of loading frame: 630*400*1530mm
|
