Spring Testing Machine ¡¤ product category

product name £º200/300kN Computer Control Spring Transverse Stiffness (Load) Testing Machine
product specifications £ºWDW-TH200/300



Technical specification

1) max.vertical test force: 200kN/300kN

2) accuracy of test force: ¡Ü¡À0.5%

3) measuring range of test force: 0.4%-100% of full scale

4) resolution: 1/¡À300000F.S

5) vertical compression space:0-810mm

6) effective test span: 610mm

7) moving speed of cross head:0.001-500mm/min

8) vertical displacement resolution: 0.01mm

9) vertical loading motor power: 5kW

10) upper pressure platen: Ø450mm

11) T-type working table:(W*L): 550*550mm

12) max. transverse test force: ¡À40kN/¡À50kN

13) accuracy of test force: ¡Ü¡À0.5%

14) measuring range of test force: 0.4%-100% of full scale

15) resolution: 1/¡À300000F.S

16) transverse stroke of crosshead:0¡«¡À100mm

17) transverse moving speed: 0.001-500mm/min

18) transverse displacement resolution: 0.01mm

19) transverse motor power: 0.75kW

20) dimension of loading frame (L*W*H): 1150*1450*2700mm

21) total power: 6.0kW

22) N.W.: 2600kg/2900kg

23) dimension of controller (L*W*H): 600*600*1650mm




¡¡
